FCS compatible CNC Pull Down Clamping Module 80 Flanged
$743.60
The RHS-C7001 Clamping Module (Ø80 mm, Flanged Base) is a precision workholding module compatible with FCS-style systems, engineered for secure and repeatable clamping of fixtures and palletized workpieces.
Made from hardened chrome steel and rated for 18,000 N clamping power, this flanged module offers exceptional rigidity, ±0.005 mm repeatability, and reliable performance in demanding EDM, CNC, and automated machining setups.
- Description
- Additional information
- Reviews (0)
Description
The RHS-C7001 Clamping Module Ø80 mm (Flanged) is a high-precision, heavy-duty workholding module designed for shops using FCS-compatible clamping systems.
Built from hardened chrome steel and engineered with a robust flanged mounting base, this module provides secure clamping, exceptional durability, and long-term stability for EDM, CNC milling, automation cells, and 5-axis machining.
With 18,000 N of clamping force, ±0.005 mm repeatability, and a rigid Ø80 mm interface, it ensures fast setups, precise repositioning, and consistent part accuracy across complex production workflows.
Key Benefits:
Heavy-duty clamping module for Ø80 mm workholding systems
Flanged base for stable and secure mounting
High clamping power for demanding machining tasks
Precision-ground surfaces for repeatable accuracy
Suitable for CNC, EDM, automation, and 5-axis machining
| RHS Part Number | RHS-C7001 |
| Model Type | Clamping Module Ø80 mm, Flanged |
| Size | 145 × 80 × 80 mm |
| Material | Chrome Steel |
| Hardness | 46–60 HRC |
| Clamping Power | 18,000 N |
| Max Torque | 30 Nm |
| Repeatability | ±0.005 mm |
| Net Weight | 3.55 kg |
| Compatibility | FCS-Compatible Ø80 mm Clamping Systems |
| Applications | CNC Milling, EDM, 5-Axis Machining, Automation |
Additional information
| Weight | 3 kg |
|---|---|
| Dimensions | 7 × 7 × 7 cm |
